Medium Refrigerated Truck body
- External and internal panel covering: pre-painted flat steel sheets in white color RAL9016 (coated with thickness of 7micron primer and 25micron final epoxy coat)
- Panel insulation is polyurethane rigid foam (density 40Kg/M3)
- Thickness 100 mm for side walls and roof, 80mm for tail door
- Floor panel made by “T” aluminum profile
- Inside and outside frame made by aluminum profiles
- Sub frame made from high tensile steel all welded construction, reinforced, painted with epoxy primer. All steel fabrication protected with anticorrosive preparation during assembly.
- Double wing door with mild steel frame, each door equipped with 4 stainless steel hinges, stainless steel external locking bar and complete with sealing PVC profiles.
- Seal inside and outside of box by PU adhesives.
- Bumper / fender / tool box
- Internal light
Options:
- European made stainless steel lock and hinges
- Floor surface by flat or checkered stainless steel
- Floor surface by checkered aluminum sheet
- Door frame made by stainless steel
- Side door 750mm * 1000mm / 900mm * 1600mm
- Steel or stainless steel railing set for meat
- Change color of outside aluminum frame
- Change color of external surface of panels
- Fix and portable insulated partition
- Small hatch
Medium Refrigerated Truck body
Medium Refrigerated Truck body
- External and internal panel covering: pre-painted flat steel sheets in white color RAL9016 (coated with thickness of 7micron primer and 25micron final epoxy coat)
- Panel insulation is polyurethane rigid foam (density 40Kg/M3)
- Thickness 100 mm for side walls and roof, 80mm for tail door
- Floor panel made by “T” aluminum profile
- Inside and outside frame made by aluminum profiles
- Sub frame made from high tensile steel all welded construction, reinforced, painted with epoxy primer. All steel fabrication protected with anticorrosive preparation during assembly.
- Double wing door with mild steel frame, each door equipped with 4 stainless steel hinges, stainless steel external locking bar and complete with sealing PVC profiles.
- Seal inside and outside of box by PU adhesives.
- Bumper / fender / tool box
- Internal light
Options:
European made stainless steel lock and hinges
Floor surface by flat or checkered stainless steel
Floor surface by checkered aluminum sheet
Door frame made by stainless steel
Side door 750mm * 1000mm / 900mm * 1600mm
Steel or stainless steel railing set for meat
Change color of outside aluminum frame
Change color of external surface of panels
Fix and portable insulated partition
Small hatch
